NEW!  Sky-Tec is proud to introduce by popular demand, Sky-Tec aircraft solenoids!



Finally there is a true, high-quality, high-performance FAA CERTIFIED OE/reproduction solenoid available for most popular piston aircraft.


Never again will you have to use overpriced "new old stock", questionable sources and non-certified tractor supply store products on your certified aircraft!



Sky-Tec has once again simply done what makes common sense.  In this case, we simply replicated the best OE solenoids using all new tooling and the highest quality materials to ensure the industry has access to exacting the real thing:  aviation (not automotive) solenoids that fit and wire the same as the originals did.  The terminals are the right size and in the right place and the internals are high quality and built to take the beating that only our smaller piston-engine aircraft can dish out.  We also enhanced inrush capability to ensure maximum performance with Sky-Tec high torque, lightweight starters.



And because we're Sky-Tec, you can be assured the price is reasonable and factory support, should you ever need it, is second to none.



No one else offers an FAA-certified solenoid at anywhere close to the same quality at anywhere close to the same price.



Available today at all our stocking dealers.  Stock up for your shop TODAY!



FAA-PMA Certified Aircraft

Starter Solenoids

FAA-PMA Certified Aircraft

Battery/Master Solenoids

FAA-PMA Certified Aircraft

Continuous Duty (Aux) Solenoids

FAA-PMA Certified FAA-PMA Certified FAA-PMA Certified
Function

Intermittent Duty, (Starter Solenoid)

Available in 12V or 24V

Activation: +V to S-Terminal

(frame is grounded by mounting)



Function

Continuous Duty (Battery/Master Solenoid)

Available in 12V or 24V

Activation: -(Ground) to S-Terminal

(floating ground frame)



Function

Continuous Duty (Aux Solenoid)

Typically used for connecting

Auxiliary (Ground) Power

Activation: Varies

See Installation Drawing for wiring

Features

AgWC contacts provide 300A in-rush capability. Much higher than OE units

Strong spring and high-current coil for quick contact opening - minimizing arcing

Single coil terminal (other end connected to case).

Features

AgWC Contacts provide 300A in-rush &
150A continuous-duty capability
Much higher than OE units

Light spring and low-current coil for excellent engagement and holding capability

Single coil terminal (other end of coil connected to Battery terminal)

Features

AgWC Contacts provide 300A in-rush &
150A continuous-duty capability
Much higher than the original units

Light spring and low-current coil for excellent engagement and holding capability

Dual coil terminals



Coil Resistance

STS-S12 (12V) - 4.18 Ohms

STS-S24 (24V) - 16.8 Ohms

Coil Resistance

STS-M12 (12V) - 16.3 Ohms

STS-M24 (24V) - 54 Ohms

Coil Resistance

STS-A12 (12V) - 16.3 Ohms

STS-A24 (24V) - 54 Ohms

How much does it cost?



STS-S12 (12V) - $69

STS-S24 (24V) - $79

from our dealers

How much does it cost?



STS-M12 (12V) - $69

STS-M24 ( 24V) - $79

from our dealers

How much does it cost?



STS-A12 (12V) - $69

STS-A24 ( 24V) - $79

from our dealers



BUY NOW



BUY NOW BUY NOW
Starter Solenoid Resources Starter Solenoid Resources Starter Solenoid Resources

PMA Eligibility

Solenoid Installation Drawing*



*Includes ICA

PMA Eligibility

Solenoid Installation Drawing*



*Includes ICA

PMA Eligibility

Solenoid Installation Drawing*



*Includes ICA



Highlights

Available NOW

FAA-PMA Certified - stop using automotive parts and operating in the 'gray area' (aka. non-conformance) of the FAR's!

Sky-Tec has retooled & upgraded the GOOD, "old-school" aircraft solenoids!

High Quality Manufacturing designed to take the beating our piston aircraft dish out

Upgraded to perform best with today's lightweight, high torque starters

Not automotive store parts with extra mystery terminals

Same OE terminal layout used for decades on our aircraft - simple to install

AgWC contacts (Silver Tungsten-Carbide vs. copper) for high-current capability, arcing resistance, oxidation resistance and long-life

Sealed all-metal case construction



Only Sky-Tec offers high quality FAA-PMA replacements for Prestolite (and other) solenoids used in Beech, Cessna, Grumman, Lake, Maule and Piper aircraft. 12 and 24 volt units.



Features:



Battery (Master) solenoids:

   Silver Tungsten-Carbide contacts provide 300A in-rush and 150A continuous-duty capability. Much higher than the original units.

   Light spring and low-current coil for excellent engagement and holding capability.

   Single coil terminal (other end of coil connected to Battery terminal)



Starter solenoids:

   Silver Tungsten-Carbide contacts provide 300A in-rush capability. Much higher than the original units.

   Strong spring and high-current coil for quick contact opening, minimizing arcing.

   Single coil terminal (other end connected to case).



Auxiliary solenoids: (used in various aircraft for ground-power, flaps, landing gear, etc.)

   Silver Tungsten-Carbide contacts provide 300A in-rush and 150A continuous-duty capability. Much higher than the original units.

   Light spring and low-current coil for excellent engagement and holding capability.

   Dual coil terminals.



Replacements for:   [  You're not really supposed to read all this jibber-jabber.  Google is.  ; )  ]



Description

Sky-Tec Part Number

Approved

Replacement

for Article

Number

Approval Basis and

Approved Design Data

Make/TCH

Eligibility

Model/Series

Eligibility

Solenoid Contactor – Battery Master

STS-M12

SAS-4201-1

Test and Computations

per 14 CFR ¤ 21.303,

DWG No: 80000

Rev: None

Date: 12/10/2013

or later FAA-approved revisions.

Alexandria Aircraft LLC

17-30A, 17-31A, 17-31ATC

Solenoid Contactor - Starter

STS-S12

SAS-4201-1

Test and Computations

per 14 CFR ¤ 21.303,

DWG No: 80000

Rev: None

Date: 12/10/2013

or later FAA-approved revisions.

Alexandria Aircraft LLC

17-30A, 17-31A, 17-31ATC

Solenoid Contactor – Battery Master

STS-M12

0411021-1





Test and Computations

per 14 CFR ¤ 21.303,

DWG No: 80000

Rev: None

Date: 12/10/2013

or later FAA-approved revisions.

Cessna Aircraft Company

170A, 170B, 190, 195

Solenoid Contactor – Auxiliary Power or Battery Master

STS-A12

0411021-1





Test and Computations

per 14 CFR ¤ 21.303,

DWG No: 80000

Rev: None

Date: 12/10/2013

or later FAA-approved revisions.

Cessna Aircraft Company

170A, 170B, 190, 195

Solenoid Contactor – Battery Master

STS-M12

0712603-1

Test and Computations

per 14 CFR ¤ 21.303,

DWG No: 80000

Rev: None

Date: 12/10/2013

or later FAA-approved revisions.

Cessna Aircraft Company

170B, 210, 210A,

Solenoid Contactor – Auxiliary Power or Battery Master

STS-A12

0712603-1

Test and Computations

per 14 CFR ¤ 21.303,

DWG No: 80000

Rev: None

Date: 12/10/2013

or later FAA-approved revisions.

Cessna Aircraft Company

170B, 210, 210A,

Solenoid Contactor – Battery Master

STS-M12

0712603-2

Test and Computations

per 14 CFR ¤ 21.303,

DWG No: 80000

Rev: None

Date: 12/10/2013

or later FAA-approved revisions.

Cessna Aircraft Company

150, 150A, 150B, 150C, 150D, 150E, FP172, 172, 172A, 172B, 172C, 172D, 172E, 172F, 175, 175A, 175B, 175C, F172, F172E, F172F, 180, 180A, 180B, 180C, 180D, 180E, 180F, 180G, 180H, 182, 182A, 182B, 182C, 182D, 182E, 182F, 182G, 182H, 185, 185A, 185B, 185C, 185D, 205, 205A, 206, U206, P206, 210B, 210C, 210D, 210E, 210F

Solenoid Contactor – Auxiliary Power or Battery Master

STS-A12

0712603-2

Test and Computations

per 14 CFR ¤ 21.303,

DWG No: 80000

Rev: None

Date: 12/10/2013

or later FAA-approved revisions.

Cessna Aircraft Company

150, 150A, 150B, 150C, 150D, 150E, 172, 172A, 172B, 172C, 172D, 172E, 172F, 175, 175A, 175B, 175C, F172E, F172F, 180, 180A, 180B, 180C, 180D, 180E, 180F, 180G, 180H, 182, 182A, 182B, 182C, 182D, 182E, 182F, 182G, 182H, 185, 185A, 185B, 185C, 185D, 205, 205A, 206, U206, P206, 210B, 210C, 210D, 210E, 210F





Solenoid Contactor – Battery Master

STS-M12

S1579-1

Test and Computations

per 14 CFR ¤ 21.303,

DWG No: 80000

Rev: None

Date: 12/10/2013

or later FAA-approved revisions.

Cessna Aircraft Company

150F, 150G, 150H, 150J, 150K, 150L, F150F, F150G, F150H, F150J, F150K, F150L, A150K, A150L, FA150K. FA150L, 172G, 172H, F172G, F172H, F172K, 177, 177A, 177B, 180H, 180J, 182J, 182K, 182L, 182M, 182N, 182P, 185E, A185E, U206A, P206A, U206B, P206B, U206C, P206C, U206D, P206D, U206E, P206E, TU206A, TP206A, TU206B, TP206B, TU206C, TP206C, TU206D, TP206D, TU206E, TP206E, 210G, T210G, 210H, T210H, 210J, T210J





Solenoid Contactor – Auxiliary Power or Battery Master

STS-A12

S1579-1

Test and Computations

per 14 CFR ¤ 21.303,

DWG No: 80000

Rev: None

Date: 12/10/2013

or later FAA-approved revisions.

Cessna Aircraft Company

150F, 150G, 150H, 150J, 150K, 150L, F150F, F150G, F150H, F150J, F150K, F150L, A150K, A150L, FA150K. FA150L, 172G, 172H, F172G, F172H, F172K, 177, 177A, 177B, 180H, 180J, 182J, 182K, 182L, 182M, 182N, 182P, 185E, A185E, U206A, P206A, U206B, P206B, U206C, P206C, U206D, P206D, U206E, P206E, TU206A, TP206A, TU206B, TP206B, TU206C, TP206C, TU206D, TP206D, TU206E, TP206E, 210G, T210G, 210H, T210H, 210J, T210J

Solenoid Contactor – Battery Master

STS-M12

S1579-2

Test and Computations

per 14 CFR ¤ 21.303,

DWG No: 80000

Rev: None

Date: 12/10/2013

or later FAA-approved revisions.

Cessna Aircraft Company

150L, 150M, F150L, F150M, A150L, A150M, FA150L, FA150M, 172I, 172K, 172L, 172M, 172N, 172P, 172Q, F172L, F172M, F172N, 177RG, F177RG, 180J, 180K, 182E, 182F, 182G, 182H, 182J, 182K, 182L, 182M, 182N, 182P, 182Q, F182P, F182Q, 185E, A185E, A185F, 188, A188, 188A, A188A, 188B, A188B, U206F, TU206F, 207, T207, 210K, T210K





Solenoid Contactor – Auxiliary Power or Battery Master

STS-A12

S1579-2

Test and Computations

per 14 CFR ¤ 21.303,

DWG No: 80000

Rev: None

Date: 12/10/2013

or later FAA-approved revisions.

Cessna Aircraft Company

150L, 150M, F150L, F150M, A150L, A150M, FA150L, FA150M, 172I, 172K, 172L, 172M, 172N, 172P, 172Q, F172L, F172M, F172N, 177RG, F177RG, 180J, 180K, 182E, 182F, 182G, 182H, 182J, 182K, 182L, 182M, 182N, 182P, 182Q, F182P, F182Q, 185E, A185E, A185F, 188, A188, 188A, A188A, 188B, A188B, U206F, TU206F, 207, T207, 210K, T210K

Solenoid Contactor – Auxiliary Power or Battery Master

STS-A12

S1660-1

Test and Computations

per 14 CFR ¤ 21.303,

DWG No: 80000

Rev: None

Date: 12/10/2013

or later FAA-approved revisions.

Cessna Aircraft Company

172D, 172E, 172F, 172G, 172H, 172I, 172K, 172L, 172M, 172N, F172H, F172K, F172L, F172M, F172N, 177, 177A, 177B, 177RG, 180H, 180J, 180K, 182K, 182L, 182M, 182N, 182P, A185E, A185F, 182P, 182Q, F182P, F182Q, 206, U206, P206, U206A, P206A, U206B, P206B, U206C, P206C, U206D, P206D, U206E, P206E, TU206A, TU206B, TU206C, TU206D, TU206E, TP206A, TP206B, TP206C, TP206D, TP206E, U206F, TU206F, 207, T207, 210G, T210G, 210H, T210H, 210J, T210J, 210K, T210K

Solenoid Contactor - Starter

STS-S12

S1660-1

AS STARTER

Test and Computations

per 14 CFR ¤ 21.303,

DWG No: 80000

Rev: None

Date: 12/10/2013

or later FAA-approved revisions.

Cessna Aircraft Company

150J, 172D, 172E, 172F, 172G, 172H, 172I, 172K

Solenoid Contactor - Starter

STS-S12

0750027-1

S1673-1

Test and Computations

per 14 CFR ¤ 21.303,

DWG No: 80000

Rev: None

Date: 12/10/2013

or later FAA-approved revisions.

Cessna Aircraft Company

180F, 180G, 180H, 185, 185A, 185B, 185C, 185D, 185E, 205, 205A, 206, U206, P206, U206A, P206A, TU206A

Solenoid Contactor - Starter

STS-S12

S1991-1

Test and Computations

per 14 CFR ¤ 21.303,

DWG No: 80000

Rev: None

Date: 12/10/2013

or later FAA-approved revisions.

Cessna Aircraft Company

150J, 150K, 150L, 150M, A150K, A150L, A150M, F150K, F150L, F150M, FA150K, FA150L, FA150M, 172K, 172L, 172M, 172N, F172L, F172M, F172N, 177RG, 182E, 182N, 182P, 182Q, F182P, F182Q, 188, A188, 188A, A188A, 188B, A188B, U206D, U206E, TP206D, TP206E, U206F, TU206F, 207, T207, 210K, T21K

Solenoid Contactor - Starter

STS-S12

SAW4206-1, SAW4204-1

Test and Computations

per 14 CFR ¤ 21.303,

DWG No: 80000

Rev: None

Date: 12/10/2013

or later FAA-approved revisions.

Cessna Aircraft Company

F172D, F172E, F172G, F172H





Solenoid Contactor - Starter

STS-S12

S1673-1

Test and Computations

per 14 CFR ¤ 21.303,

DWG No: 80000

Rev: None

Date: 12/10/2013

or later FAA-approved revisions.

Cessna Aircraft Company

177, 177A, 177B, 182E, 182F, 182G, 180H, 182H, 182J, 182K, 182L, 182M A185E, 188, A188, U206B, TU206B, TP206B, U206C, TU206C, TP206C, U206D, TP206D, 207, T207

Solenoid Contactor – Battery Master

STS-M24

S1578-1

Test and Computations

per 14 CFR ¤ 21.303,

DWG No: 80000

Rev: None

Date: 12/10/2013

or later FAA-approved revisions.

Cessna Aircraft Company

337, 337A, 337B, T337B, 337C, T337C, 337D, T337D, 337E, T337E, F337E, FT337E, 337F, T337F F337F, FT337F

Solenoid Contactor – Auxiliary Power or Battery Master

STS-A24

S1578-1

Test and Computations

per 14 CFR ¤ 21.303,

DWG No: 80000

Rev: None

Date: 12/10/2013

or later FAA-approved revisions.

Cessna Aircraft Company

337, 337A, 337B, T337B, 337C, T337C, 337D, T337D, 337E, T337E, F337E, FT337E, 337F, T337F F337F, FT337F

Solenoid Contactor – Battery Master

STS-M24

S1580-1

Test and Computations

per 14 CFR ¤ 21.303,

DWG No: 80000

Rev: None

Date: 12/10/2013

or later FAA-approved revisions.

Cessna Aircraft Company

152, A152, F152, FA152, 172N, F172N, 180K, A185F, 182Q, F182Q, 188, A188, 188A, A188A, 188B, A188B, TU206E, U206F, TU206F, 207, T207, 210L, T210L, 337G, F337G





Solenoid Contactor – Battery Master

STS-M24

STS-S2475-1

Test and Computations

per 14 CFR ¤ 21.303,

DWG No: 80000

Rev: None

Date: 12/10/2013

or later FAA-approved revisions.

Cessna Aircraft Company

152, A152, F152, FA152, 172P, F172P, 180K, 182R, A185F

Solenoid Contactor – Auxiliary Power or Battery Master

STS-A24

STS-S2475-1

Test and Computations

per 14 CFR ¤ 21.303,

DWG No: 80000

Rev: None

Date: 12/10/2013

or later FAA-approved revisions.

Cessna Aircraft Company

152, A152, F152, FA152, 172P, F172P, 180K, 182R, A185F

Solenoid Contactor – Battery Master

STS-M24

STS-S2475-1

Test and Computations

per 14 CFR ¤ 21.303,

DWG No: 80000

Rev: None

Date: 12/10/2013

or later FAA-approved revisions.

Cessna Aircraft Company

172P, 172Q, F172P, 180K, A185F, 182R

Solenoid Contactor – Battery Master

STS-M24

STS-S2475-2

Test and Computations

per 14 CFR ¤ 21.303,

DWG No: 80000

Rev: None

Date: 12/10/2013

or later FAA-approved revisions.

Cessna Aircraft Company

152, A152, F152, FA152, 172P, 172Q, F172P, 180K, 182R, A185F, 210N, T210N, T210R 210R

Solenoid Contactor – Auxiliary Power or Battery Master

STS-A24

STS-S2475-2

Test and Computations

per 14 CFR ¤ 21.303,

DWG No: 80000

Rev: None

Date: 12/10/2013

or later FAA-approved revisions.

Cessna Aircraft Company

152, A152, F152, FA152, 172P, 172Q, F172P, R172, 180K, 182R, A185F, 210N, T210N, T210R 210R

Solenoid Contactor – Battery Master

STS-M24

STS-S2475-2

AS AUX POWER

Test and Computations

per 14 CFR ¤ 21.303,

DWG No: 80000

Rev: None

Date: 12/10/2013

or later FAA-approved revisions.

Cessna Aircraft Company

180K, A185F

Solenoid Contactor - Starter

STS-S24

S1577-1

AS STARTER

Test and Computations

per 14 CFR ¤ 21.303,

DWG No: 80000

Rev: None

Date: 12/10/2013

or later FAA-approved revisions.

Cessna Aircraft Company

152, A152, F152, FA152, 172N, F172N, 180K, A185F, 182Q, F182Q, 188, A188, 188A, A188A, 188B, A188B, U206E, TU206E, U206F, TU206F, 207, T207, 210L, T210L, 337, 337A, 337B, T337B, 337C, T337C, 337D, T337D, 337E, T337E, F337E, FT337E, 337F, T337F F337F, FT337F, 337G, T337G, F337G

Solenoid Contactor - Starter

STS-S24

S1577-1

AS AUX POWER

Test and Computations

per 14 CFR ¤ 21.303,

DWG No: 80000

Rev: None

Date: 12/10/2013

or later FAA-approved revisions.

Cessna Aircraft Company

172N, 182Q, 182R, F182Q, U206E, TU206E, U206F, TU206F, 207, T207, 210L, T210L, 337B, T337B, 337C, T337C, 337D, T337D, 337E, T337E, F337E, FT337E, 337F, T337F F337F, FT337F, 337G, T337G, F337G

Solenoid Contactor - Starter

STS-S24

STS-S2443-1, STS-S2443-2

Test and Computations

per 14 CFR ¤ 21.303,

DWG No: 80000

Rev: None

Date: 12/10/2013

or later FAA-approved revisions.

Cessna Aircraft Company

152, A152, F152, FA152, 172N, 172P, 172Q, F172N, F172P, 182Q, 182R, 210N, T210N, 210R, T210R

Solenoid Contactor - Starter

STS-S12

63122

Prestolite SAN4204

Test and Computations

per 14 CFR ¤ 21.303,

DWG No: 80000

Rev: None

Date: 12/10/2013

or later FAA-approved revisions.

Commander Aircraft Corporation

112

Solenoid Contactor - Starter

STS-S12

SAZ4201E-1

Test and Computations

per 14 CFR ¤ 21.303,

DWG No: 80000

Rev: None

Date: 12/10/2013

or later FAA-approved revisions.

Commander Aircraft Corporation

112, 112B, 112TC, 112TCA, 114, 114A

Solenoid Contactor - Starter

STS-S24

SAZ4401

Test and Computations

per 14 CFR ¤ 21.303,

DWG No: 80000

Rev: None

Date: 12/10/2013

or later FAA-approved revisions.

Commander Aircraft Corporation

114B, 114TC

Solenoid Contactor – Auxiliary Power or Battery Master

STS-A12

71-311222

71-311222-5

Test and Computations

per 14 CFR ¤ 21.303,

DWG No: 80000

Rev: None

Date: 12/10/2013

or later FAA-approved revisions.

Commander Aircraft Corporation

112, 112B, 112TC, 112TCA, 114, 114A

Solenoid Contactor – Auxiliary Power or Battery Master

STS-A24

70-907

Test and Computations

per 14 CFR ¤ 21.303,

DWG No: 80000

Rev: None

Date: 12/10/2013

or later FAA-approved revisions.

Commander Aircraft Corporation

114B, 114TC

Solenoid Contactor – Battery Master

STS-M12

62551

RBM Controls 7111224

Test and Computations

per 14 CFR ¤ 21.303,

DWG No: 80000

Rev: None

Date: 12/10/2013

or later FAA-approved revisions.

Commander Aircraft Corporation

112

Solenoid Contactor – Auxiliary Power or Battery Master

STS-A12

62551

RBM Controls 7111224

Test and Computations

per 14 CFR ¤ 21.303,

DWG No: 80000

Rev: None

Date: 12/10/2013

or later FAA-approved revisions.

Commander Aircraft Corporation

112

Solenoid Contactor – Battery Master

STS-M12

48296-9

Test and Computations

per 14 CFR ¤ 21.303,

DWG No: 80000

Rev: None

Date: 12/10/2013

or later FAA-approved revisions.

Commander Aircraft Corporation

112, 112B, 112TC, 112TCA, 114, 114A

Solenoid Contactor – Auxiliary Power or Battery Master

STS-A12

48296-9

Test and Computations

per 14 CFR ¤ 21.303,

DWG No: 80000

Rev: None

Date: 12/10/2013

or later FAA-approved revisions.

Commander Aircraft Corporation

112, 112B, 112TC, 112TCA, 114, 114A

Solenoid Contactor – Battery Master

STS-M24

70-911

70-907

Test and Computations

per 14 CFR ¤ 21.303,

DWG No: 80000

Rev: None

Date: 12/10/2013

or later FAA-approved revisions.

Commander Aircraft Corporation

114B, 114TC

Solenoid Contactor – Auxiliary Power or Battery Master

STS-A24

70-911

70-907

Test and Computations

per 14 CFR ¤ 21.303,

DWG No: 80000

Rev: None

Date: 12/10/2013

or later FAA-approved revisions.

Commander Aircraft Corporation

114B, 114TC

Solenoid Contactor - Battery Master

STS-M12

8781-2

Test and Computations

per 14 CFR ¤ 21.303,

DWG No: 80000

Rev: None

Date: 12/10/2013

or later FAA-approved revisions.

True Flight Holdings, LLC

AA-1A, AA-1B, AA-5, AA-5A, AA-5B

Solenoid Contactor - Starter

STS-S12

Prestolite SAW4217-1

Test and Computations

per 14 CFR ¤ 21.303,

DWG No: 80000

Rev: None

Date: 12/10/2013

or later FAA-approved revisions.

True Flight Holdings, LLC

AA-1, AA-1A, AA-5

Solenoid Contactor - Starter

STS-S12

Prestolite SAW4204-1

Test and Computations

per 14 CFR ¤ 21.303,

DWG No: 80000

Rev: None

Date: 12/10/2013

or later FAA-approved revisions.

True Flight Holdings, LLC

AA-1A, AA-1B, AA-5, AA-5A, AA-5B

Solenoid Contactor – Battery Master

STS-M24

70-903

Test and Computations

per 14 CFR ¤ 21.303,

DWG No: 80000

Rev: None

Date: 12/10/2013

or later FAA-approved revisions.

True Flight Holdings, LLC

AG-5B

Solenoid Contactor – Auxiliary Power or Battery Master

STS-A24

70-903

Test and Computations

per 14 CFR ¤ 21.303,

DWG No: 80000

Rev: None

Date: 12/10/2013

or later FAA-approved revisions.

True Flight Holdings, LLC

AG-5B

Solenoid Contactor - Starter

STS-S24

70-915

Test and Computations

per 14 CFR ¤ 21.303,

DWG No: 80000

Rev: None

Date: 12/10/2013

or later FAA-approved revisions.

True Flight Holdings, LLC

AG-5B

Solenoid Contactor – Auxiliary Power or Battery Master

STS-A12

Prestolite 8781-2

Test and Computations

per 14 CFR ¤ 21.303,

DWG No: 80000

Rev: None

Date: 12/10/2013

or later FAA-approved revisions.

SOCATA. S.A. Socata Groupe Aerospatiale

GA-7

Solenoid Contactor – Battery Master

STS-M12

6041H187

Test and Computations

per 14 CFR ¤ 21.303,

DWG No: 80000

Rev: None

Date: 12/10/2013

or later FAA-approved revisions.

Beechcraft Corporation

35-33, 35-A33,

35-B33, 35-C33, 35-C33A, E33, E33A, F33, G33, F33A, F33C, H35, J35, K35, M35, N35, P35, S35, V35, V35A, V35B

Solenoid Contactor – Auxiliary Power or Battery Master

STS-A12

6041H187

Test and Computations

per 14 CFR ¤ 21.303,

DWG No: 80000

Rev: None

Date: 12/10/2013

or later FAA-approved revisions.

Beechcraft Corporation

35-33, 35-A33,

35-B33, 35-C33, 35-C33A, E33, E33A, F33, G33, F33A, F33C, H35, J35, K35, M35, N35, P35, S35, V35, V35A, V35B

Solenoid Contactor – Battery Master

STS-M12

6041H105

Test and Computations

per 14 CFR ¤ 21.303,

DWG No: 80000

Rev: None

Date: 12/10/2013

or later FAA-approved revisions.

Beechcraft Corporation

35, A35, B35, C35, D35, E35, F35, G35

Solenoid Contactor – Auxiliary Power or Battery Master

STS-A12

6041H105

Test and Computations

per 14 CFR ¤ 21.303,

DWG No: 80000

Rev: None

Date: 12/10/2013

or later FAA-approved revisions.

Beechcraft Corporation

35, A35, B35, C35, D35, E35, F35, G35

Solenoid Contactor - Starter

STS-S12

SAW4204

Test and Computations

per 14 CFR ¤ 21.303,

DWG No: 80000

Rev: None

Date: 12/10/2013

or later FAA-approved revisions.

Beechcraft Corporation

V35B

Solenoid Contactor - Starter

STS-S12

1464

Test and Computations

per 14 CFR ¤ 21.303,

DWG No: 80000

Rev: None

Date: 12/10/2013

or later FAA-approved revisions.

Beechcraft Corporation

35, A35

Solenoid Contactor - Starter

STS-S12

1453

Test and Computations

per 14 CFR ¤ 21.303,

DWG No: 80000

Rev: None

Date: 12/10/2013

or later FAA-approved revisions.

Beechcraft Corporation

B35, C35, D35, E35, F35, G35

Solenoid Contactor - Starter

STS-S12

1114213

Test and Computations

per 14 CFR ¤ 21.303,

DWG No: 80000

Rev: None

Date: 12/10/2013

or later FAA-approved revisions.

Beechcraft Corporation

35-33, 35-A33,

35-B33, 35-C33, 35-C33A, E33, E33A, F33, G33, F33A, F33C, H35, J35, K35, M35, N35, P35, S35, V35, V35A, V35B

Solenoid Contactor - Starter

STS-S12

36-3008-1

Test and Computations

per 14 CFR ¤ 21.303,

DWG No: 80000

Rev: None

Date: 12/10/2013

or later FAA-approved revisions.

Beechcraft Corporation

F33C

Solenoid Contactor – Auxiliary Power or Battery Master

STS-A12

70-111224-5

Test and Computations

per 14 CFR ¤ 21.303,

DWG No: 80000

Rev: None

Date: 12/10/2013

or later FAA-approved revisions.

Beechcraft Corporation

F33C

Solenoid Contactor – Battery Master

STS-M24

6041H189

Test and Computations

per 14 CFR ¤ 21.303,

DWG No: 80000

Rev: None

Date: 12/10/2013

or later FAA-approved revisions.

Beechcraft Corporation

F33A, F33C, V35B, 95-55,

95- A55,

95-B55, 95- C55, D55, E55, 58, 36, A36, A36TC, B36TC

Solenoid Contactor – Auxiliary Power or Battery Master

STS-A24

6041H189

Test and Computations

per 14 CFR ¤ 21.303,

DWG No: 80000

Rev: None

Date: 12/10/2013

or later FAA-approved revisions.

Beechcraft Corporation

F33A, F33C, V35B, 95-55,

95-A55,

95-B55, 95- C55, D55, E55, 58, 36, A36, A36TC, B36TC

Solenoid Contactor – Auxiliary Power or Battery Master

STS-S24

6041H190

Test and Computations

per 14 CFR ¤ 21.303,

DWG No: 80000

Rev: None

Date: 12/10/2013

or later FAA-approved revisions.

Beechcraft Corporation

F33A, F33C, V35B, 95-55,

95- A55, 95-B55, 95-C55, D55, E55, 58, 36, A36, A36TC, B36TC

Solenoid Contactor – Battery Master

STS-M12

71-111221-5

Test and Computations

per 14 CFR ¤ 21.303,

DWG No: 80000

Rev: None

Date: 12/10/2013

or later FAA-approved revisions.

Maule Aerospace Technology, Inc.

M-4-210,

M-5-180C,

M-5-200,

M-5-210C,

M-5-210TC,

M-5-220C,

M-5-235C,

M-6-180, M-6-235, M-7-235,

M-7-235A,

M-7-235B,

M-7-235C,

M-7-260,

M-7-260C,

MX-7-160,

MX-7-160C,

MX-7-180,

MX-7-180A,

MX-7-180B,

MX-7-180C,

MX-7-180AC, MX-7-235,

MT-7-235,

MT-7-260,

MXT-7-160, MXT-7-180, MXT-7-180A

Solenoid Contactor – Auxiliary Power or Battery Master

STS-A12

71-111221-5

Test and Computations

per 14 CFR ¤ 21.303,

DWG No: 80000

Rev: None

Date: 12/10/2013

or later FAA-approved revisions.

Maule Aerospace Technology, Inc.

M-4-210,

M-5-180C,

M-5-200,

M-5-210C,

M-5-210TC,

M-5-220C,

M-5-235C,

M-6-180, M-6-235, M-7-235,

M-7-235A,

M-7-235B,

M-7-235C,

M-7-260,

M-7-260C,

MX-7-160,

MX-7-160C,

MX-7-180,

MX-7-180A,

MX-7-180B,

MX-7-180C,

MX-7-180AC, MX-7-235,

MT-7-235,

MT-7-260,

MXT-7-160, MXT-7-180, MXT-7-180A

Solenoid Contactor – Battery Master

STS-M12

RBM-2295-7

1114213

Test and Computations

per 14 CFR ¤ 21.303,

DWG No: 80000

Rev: None

Date: 12/10/2013

or later FAA-approved revisions.

Maule Aerospace Technology, Inc.

M-4-180C,

M-4-210, M-4-220, M-4-210C,

M-5-180C,

M-5-235C,

M-6-180, M-6-235,

M-7-235,

MX-7-180,

MX-7-235,

MXT-7-160, MXT-7-180A, MX-7-180B,

MX-7-180C

Solenoid Contactor – Auxiliary Power or Battery Master

STS-A12

RBM-2295-7

1114213

Test and Computations

per 14 CFR ¤ 21.303,

DWG No: 80000

Rev: None

Date: 12/10/2013

or later FAA-approved revisions.

Maule Aerospace Technology, Inc.

M-4-180C,

M-4-210, M-4-220, M-5-180C,

M-5-235C,

M-6-180, M-6-235,

M-7-235,

MX-7-180,

MX-7-235,

MXT-7-160, MXT-7-180A, MX-7-180B,

MX-7-180C

Solenoid Contactor - Starter

STS-S12

70-112225-5

1118823

SAW 4201

SAW 4203

SAW 4204

Test and Computations

per 14 CFR ¤ 21.303,

DWG No: 80000

Rev: None

Date: 12/10/2013

or later FAA-approved revisions.

Maule Aerospace Technology, Inc.

M-4-180C,

M-4-210, M-4-220, MX-7-160,

MX-7-160C,

MX-7-180A,

MX-7-180B,

MX-7-180C,

MT-7-260,

MT-7-235,

MXT-7-160, MXT-7-180, MXT-7-180A, MX-7-180AC

Solenoid Contactor - Starter

STS-S12

70-112225-5

SAZ-4201E

Test and Computations

per 14 CFR ¤ 21.303,

DWG No: 80000

Rev: None

Date: 12/10/2013

or later FAA-approved revisions.

Maule Aerospace Technology, Inc.

M-7-235,

M-7-235A,

M-7-235B,

M-7-235C,

M-7-260,

M-7-260C,

MX-7-160,

MX-7-160C,

MX-7-180,

MX-7-180A,

MX-7-180B,

MX-7-180C,

MX-7-180AC, MX-7-235,

MT-7-235,

MT-7-260,

MXT-7-160, MXT-7-180, MXT-7-180A

Solenoid Contactor - Starter

STS-S12

70-112225-5

Test and Computations

per 14 CFR ¤ 21.303,

DWG No: 80000

Rev: None

Date: 12/10/2013

or later FAA-approved revisions.

Maule Aerospace Technology, Inc.

M-5-180C,

M-5-200,

M-5-220C,

M-5-23C,

M-6-180,

M-6-235

Solenoid Contactor - Starter

STS-S12

SAW 4204

Test and Computations

per 14 CFR ¤ 21.303,

DWG No: 80000

Rev: None

Date: 12/10/2013

or later FAA-approved revisions.

Maule Aerospace Technology, Inc.

M-5-210C,

M-5-210TC

Solenoid Contactor - Starter

STS-S12

DR 1114213,

DR 1118823

Test and Computations

per 14 CFR ¤ 21.303,

DWG No: 80000

Rev: None

Date: 12/10/2013

or later FAA-approved revisions.

Maule Aerospace Technology, Inc.

M-4-210

Solenoid Contactor – Battery Master

STS-M24

71-117226-5

Test and Computations

per 14 CFR ¤ 21.303,

DWG No: 80000

Rev: None

Date: 12/10/2013

or later FAA-approved revisions.

Maule Aerospace Aerospace Technology, Inc.

M-6-180, M-6-235, M-7-235,

M-7-235A,

M-7-235B,

M-7-235C,

M-7-260,

M-7-260C,

MX-7-180,

MX-7-180A,

MX-7-180B,

MX-7-235,

MXT-7-160, MXT-7-180, MXT-7-180A,

M-8-235

Solenoid Contactor – Auxiliary Power or Battery Master

STS-A24

71-117226-5

Test and Computations

per 14 CFR ¤ 21.303,

DWG No: 80000

Rev: None

Date: 12/10/2013

or later FAA-approved revisions.

Maule Aerospace Aerospace Technology, Inc.

M-6-180, M-6-235, M-7-235,

M-7-235A,

M-7-235B,

M-7-235C,

M-7-260,

M-7-260C,

MX-7-180,

MX-7-180A,

MX-7-180B,

MX-7-235,

MXT-7-160, MXT-7-180, MXT-7-180A,

M-8-235

Solenoid Contactor - Starter

STS-S24

70-118225-5

Test and Computations

per 14 CFR ¤ 21.303,

DWG No: 80000

Rev: None

Date: 12/10/2013

or later FAA-approved revisions.

Maule Aerospace Aerospace Technology, Inc.

M-6-180, M-6-235, M-7-235,

M-7-235A,

M-7-235B,

M-7-235C,

M-7-260,

M-7-260C,

MX-7-180,

MX-7-180A,

MX-7-180B,

MX-7-235,

MXT-7-160, MXT-7-180, MXT-7-180A,

M-8-235

Solenoid Contactor – Battery Master

STS-M12

800128

Test and Computations

per 14 CFR ¤ 21.303,

DWG No: 80000

Rev: None

Date: 12/10/2013

or later FAA-approved revisions.

Mooney Aircraft Corporation

M20C, M20D, M20E

Solenoid Contactor - Starter

STS-S12

#001464

Test and Computations

per 14 CFR ¤ 21.303,

DWG No: 80000

Rev: None

Date: 12/10/2013

or later FAA-approved revisions.

Mooney Aircraft Corporation

M20C, M20D, M20E

Solenoid Contactor – Battery Master

STS-M12

6041H231

Test and Computations

per 14 CFR ¤ 21.303,

DWG No: 80000

Rev: None

Date: 12/10/2013

or later FAA-approved revisions.

Mooney Aircraft Corporation

M20F, M20J

Solenoid Contactor - Starter

STS-S12

#001466

Test and Computations

per 14 CFR ¤ 21.303,

DWG No: 80000

Rev: None

Date: 12/10/2013

or later FAA-approved revisions.

Mooney Aircraft Corporation

M20F

Solenoid Contactor – Battery Master

STS-M12

24059, 6041H105A

Test and Computations

per 14 CFR ¤ 21.303,

DWG No: 80000

Rev: None

Date: 12/10/2013

or later FAA-approved revisions.

Mooney Aircraft Corporation

M20K

Solenoid Contactor – Auxiliary Power or Battery Master

STS-A12

24059, 6041H105A

Test and Computations

per 14 CFR ¤ 21.303,

DWG No: 80000

Rev: None

Date: 12/10/2013

or later FAA-approved revisions.

Mooney Aircraft Corporation

M20K

Solenoid Contactor – Starter

STS-S12

24059, 6041H105A

Test and Computations

per 14 CFR ¤ 21.303,

DWG No: 80000

Rev: None

Date: 12/10/2013

or later FAA-approved revisions.

Mooney Aircraft Corporation

M20K

Solenoid Contactor - Starter

STS-S12

SAZ-4201E, SAZ-9201A, 6041H105A

Test and Computations

per 14 CFR ¤ 21.303,

DWG No: 80000

Rev: None

Date: 12/10/2013

or later FAA-approved revisions.

Mooney Aircraft Corporation

M20J

Solenoid Contactor – Battery Master

STS-M24

6041H202

Test and Computations

per 14 CFR ¤ 21.303,

DWG No: 80000

Rev: None

Date: 12/10/2013

or later FAA-approved revisions.

Mooney Aircraft Corporation

M20J, M20K, M20M, M20R, M20S

Solenoid Contactor – Auxiliary Power or Battery Master

STS-A24

6041H202

Test and Computations

per 14 CFR ¤ 21.303,

DWG No: 80000

Rev: None

Date: 12/10/2013

or later FAA-approved revisions.

Mooney Aircraft Corporation

M20M, M20R, M20S

Solenoid Contactor – Auxiliary Power or Battery Master

STS-A24

6041H202A

Test and Computations

per 14 CFR ¤ 21.303,

DWG No: 80000

Rev: None

Date: 12/10/2013

or later FAA-approved revisions.

Mooney Aircraft Corporation

M20J, M20K

Solenoid Contactor - Starter

STS-S24

6041H202, 6041H202A

Test and Computations

per 14 CFR ¤ 21.303,

DWG No: 80000

Rev: None

Date: 12/10/2013

or later FAA-approved revisions.

Mooney Aircraft Corporation

M20J, M20M

Solenoid Contactor – Starter

STS-S12

487 149 (001464)

Test and Computations

per 14 CFR ¤ 21.303,

DWG No: 80000

Rev: None

Date: 12/10/2013

or later FAA-approved revisions.

Piper Aircraft, Inc

PA-23-235, PA-23-250

Solenoid Contactor – Starter

STS-S12

99130-02 (487 169)

Test and Computations

per 14 CFR ¤ 21.303,

DWG No: 80000

Rev: None

Date: 12/10/2013

or later FAA-approved revisions.

Piper Aircraft, Inc

PA-24-180,

PA-24-250,

PA-24-260,

PA-28-140,

PA-28-150,

PA-28-160,

PA-28-180,

PA-28-235,

PA-28S-160,

PA-28S-180,

PA-28R-180,

PA-28R-200,

PA-28-151,

PA-28R-201,

PA-28R-201T,

PA-28RT-201,

PA-28RT-201T, PA-32-301,

PA-32-301T,

PA-32R-301,

PA-32R-301T,

PA-32RT-300,

PA-32RT-301T, PA-34-200,

PA-34-200T,

PA-38-112,

PA-44-180,

PA-44-180T

Solenoid Contactor - Starter

STS-M12

484 373 (24059)

Test and Computations

per 14 CFR ¤ 21.303,

DWG No: 80000

Rev: None

Date: 12/10/2013

or later FAA-approved revisions.

Piper Aircraft, Inc

PA-23-235,

PA-23-250,

PA-24-180,

PA-24-250,

PA-24-260,

PA-28-140,

PA-28-150,

PA-28-151,

PA-28-160,

PA-28-180,

PA-28-235,

PA-28R-180,

PA-28R-201,

PA-28R-201T,

PA-28RT-201,

PA-28RT-201T, PA-32-301,

PA-32-301T,

PA-32R-301,

PA-32R-301T,

PA-32RT-300,

PA-32RT-301T, PA-34-200,

PA-34-200T,

PA-38-112,

PA-44-180,

PA-44-180T

Solenoid Contactor – Auxiliary Power or Battery Master

STS-A12

484 373 (24059)

Test and Computations

per 14 CFR ¤ 21.303,

DWG No: 80000

Rev: None

Date: 12/10/2013

or later FAA-approved revisions.

Piper Aircraft, Inc

PA-23-235,

PA-23-250,

PA-24-180,

PA-24-250,

PA-24-260,

PA-28-140,

PA-28-150,

PA-28-151,

PA-28-160,

PA-28-180,

PA-28-235,

PA-28R-180,

PA-28R-201,

PA-28R-201T,

PA-28RT-201,

PA-28RT-201T, PA-32-301,

PA-32-301T,

PA-32R-301,

PA-32R-301T,

PA-32RT-300,

PA-32RT-301T, PA-34-200,

PA-34-200T,

PA-38-112,

PA-44-180,

PA-44-180T

Solenoid Contactor - Starter

STS-S24

487 152 (001 466)

Test and Computations

per 14 CFR ¤ 21.303,

DWG No: 80000

Rev: None

Date: 12/10/2013

or later FAA-approved revisions.

Piper Aircraft, Inc

PA-23-235,

PA-23-250,

PA-31, PA-31-300, PA-31-325

Solenoid Contactor - Starter

STS-S24

2698-008 (584-420)

Test and Computations

per 14 CFR ¤ 21.303,

DWG No: 80000

Rev: None

Date: 12/10/2013

or later FAA-approved revisions.

Piper Aircraft, Inc

PA-34-220T

Solenoid Contactor - Starter

STS-S24

26898-03

Test and Computations

per 14 CFR ¤ 21.303,

DWG No: 80000

Rev: None

Date: 12/10/2013

or later FAA-approved revisions.

Piper Aircraft, Inc

PA-46-310P,

PA-46-350P

Solenoid Contactor – Battery Master

STS-M24

487 167 (26898-05)

Test and Computations

per 14 CFR ¤ 21.303,

DWG No: 80000

Rev: None

Date: 12/10/2013

or later FAA-approved revisions.

Piper Aircraft, Inc

PA-23-235,

PA-23-250,

PA-31, PA-31-300, PA-31-325,

PA-34-220T,

PA-46-310P,

PA-46-350P

Solenoid Contactor – Auxiliary Power or Battery Master

STS-A24

487 167 (26898-05)

Test and Computations

per 14 CFR ¤ 21.303,

DWG No: 80000

Rev: None

Date: 12/10/2013

or later FAA-approved revisions.

Piper Aircraft, Inc

PA-23-235,

PA-23-250,

PA-31, PA-31-300, PA-31-325,

PA-34-220T,

PA-46-310P,

PA-46-350P

Solenoid Contactor - Starter

STS-S24

NOR7.369-1

Test and Computations

per 14 CFR ¤ 21.303,

DWG No: 80000

Rev: None

Date: 12/10/2013

or later FAA-approved revisions.

Vulcanair S.p.A

P.68, P.68B, P.68C, P.68C-TC, P.68 ŇObserverÓ, P.68 ŇObserver 2Ó, P.68R

Solenoid Contactor – Battery Master

STS-M24

NOR7-369-2

Test and Computations

per 14 CFR ¤ 21.303,

DWG No: 80000

Rev: None

Date: 12/10/2013

or later FAA-approved revisions.

Vulcanair S.p.A

P.68, P.68B, P.68C, P.68C-TC, P.68 ŇObserverÓ, P.68 ŇObserver 2Ó, P.68R





SOLENOIDS:

WHAT'S THE POINT?



Here's the deal with solenoids:



Back in the day, there were mechanical solenoids - in industry, automotive, marine, and of course our adored aviation industry.



And while most industries stayed with the times and transitioned to solid state relays, our beloved aircraft remained stuck in time, as they are so often, certified with mechanical solenoids that were once on the aircraft type certificates and never to change.



But let's admit, when they were good, mechanical solenoids were, well, GOOD.  The problem wasn't the solenoid, the problem became the disappearance of reliable sources of suitable mechanical solenoids.  Aircraft manufacturers scrambled finding solenoids overseas (cheap but unreliable) or buying up all new old stock they could get their hands on (making the products very expensive).  But who would be foolish enough to invest the huge sums of time, effort and expense tooling up for a product design that hasn't changed in 50+ years.  Sky-Tec!  That's who!



And so Sky-Tec is extremely proud to offer its customers REAL aviation solenoids once again.



Sky-Tec solenoids are built out of the same "good stuff" that the original OE starters were built with in the good old days.  Okay, sure, we took the opportunity to make a few slight improvements (continuous current load capacity and silver tungsten-carbide terminals) but by and large, the goal was simply to get back to the good stuff:  mechanical solenoids that fit like the OE solenoids fit, had the same number and same size of terminals as the OE solenoids and put those terminals in the same location making replacing your aircraft solenoid simple and easy.



And of course, Sky-Tec found a way to make it cost as little as possible.  The investment wasn't cheap, but we seriously think with your help we can sell enough of these to keep the prices well south of one "airplane bill."  So please, by all means, do your part and buy a few TODAY to help that cause!



Lycoming Starters ] Continental Starters ] Other Starters ] [ FAA PMA Solenoids ] Sky-Tec Fit Guide ] Eligibility ] Troubleshooting ] Warranty ] Tech Talk ] Customer Care ] About Us ] News ] Contact Us ] Buy One Now ]

350 Howard Clemmons Rd  Granbury, Texas  76048
1-800-476-7896   info@skytecair.com
Copyright © 2002 Sky-Tec Partners LTD.
